標準可換鉆套尺寸表(GB2264-80) d 公差F7 D 公差m6 D1 H h h1 C C1 C2 e m 單價(元) 1.5~1.9 +0.006~+0.016 8 +0.006~+0.015 15 16 8 3 0.5 1 1.25 1.5 4.2 24 2~2.9 +0.006~+0.016 8 +0.006~+0.015 15 16 8 3 0.5 1 1.25 1.5 4.2 24 3~3.9 +0.006~+0.016 8 +0.006~+0.015 15 16 8 3 0.5 1 1.25 1.5 4.2 24 4~4.9 +0.010~+0.022 10 +0.006~+0.015 18 20 8 3 0.5 1 1.25 1.5 5.5 20 5~5.9 +0.010~+0.022 10 +0.006~+0.015 18 20 8 3 0.5 1 1.25 1.5 5.5 16 6~6.9 +0.013~+0.028 12 +0.007~+0.018 22 20 10 4 0.5 1 1.5 2 7 13 7~7.9 +0.013~+0.028 12 +0.007~+0.018 22 20 10 4 0.5 1 1.5 2 7 13 8~8.9 +0.013~+0.028 15 +0.007~+0.018 26 28 10 4 0.5 2 1.5 2 9 14 9~9.9 +0.013~+0.028 15 +0.007~+0.018 26 28 10 4 0.5 2 1.5 2 9 14 10~10.9 +0.016~+0.034 18 +0.007~+0.018 30 28 10 4 0.5 2 1.5 2 11 17 11~11.9 +0.016~+0.034 18 +0.007~+0.018 30 28 10 4 0.5 2 1.5 2 11 17 12~12.9 +0.016~+0.034 22 +0.008~+0.021 34 36 12 5.5 0.5 2 2.5 2 12 19 13~13.9 +0.016~+0.034 22 +0.008~+0.021 34 36 12 5.5 0.5 2 2.5 2 12 19 14~14.9 +0.016~+0.034 22 +0.008~+0.021 34 36 12 5.5 1 2 2.5 2 12 20 15~15.9 +0.016~+0.034 26 +0.008~+0.021 39 36 12 5.5 1 2 2.5 2.5 14.5 25 16~16.9 +0.016~+0.034 26 +0.008~+0.021 39 36 12 5.5 1 2 2.5 2.5 14.5 25 17~17.9 +0.016~+0.034 26 +0.008~+0.021 39 36 12 5.5 1 2 2.5 2.5 14.5 25 18~18.9 +0.020~+0.041 30 +0.008~+0.021 46 45 12 5.5 1 3 2.5 2.5 18 26 19~19.9 +0.020~+0.041 30 +0.008~+0.021 46 45 12 5.5 1 3 2.5 2.5 18 26 20~20.9 +0.020~+0.041 30 +0.008~+0.021 46 45 12 5.5 1 3 2.5 2.5 18 28 21~21.9 +0.020~+0.041 30 +0.008~+0.021 46 45 12 5.5 1 3 2.5 2.5 18 28 22~22.9 +0.020~+0.041 35 +0.009~+0.025 52 45 12 5.5 1 3 2.5 2.5 21 30 23~23.9 +0.020~+0.041 35 +0.009~+0.025 52 45 12 5.5 1 3 2.5 2.5 21 30 24~24.9 +0.020~+0.041 35 +0.009~+0.025 52 45 12 5.5 1 3 2.5 2.5 21 30 25~25.9 +0.020~+0.041 35 +0.009~+0.025 52 45 12 5.5 1 3 2.5 2.5 21 40 26~26.9 +0.020~+0.041 42 +0.009~+0.025 59 56 12 5.5 1 3 3 2.5 21 40 27~27.9 +0.020~+0.041 42 +0.009~+0.025 59 56 12 5.5 1 3 3 2.5 24.5 40 28~28.9 +0.020~+0.041 42 +0.009~+0.025 59 56 12 5.5 1 3 3 2.5 24.5 40 29~29.9 +0.020~+0.041 42 +0.009~+0.025 59 56 12 5.5 1 3 3 2.5 24.5 40 30~30.9 +0.025~+0.050 48 +0.009~+0.025 66 56 16 7 1 3 3 2.5 27 50
|
|
